Vitawin Latch 3 Hooks 2 Rollers Double Spindle Multipoint Door Lock (top hook to spindle = 610mm)
Vitawin Latch 3 Hooks 2 Rollers Double Spindle Multipoint Door Lock (top hook to spindle = 610mm) - Image 2
Vitawin Latch 3 Hooks 2 Rollers Double Spindle Multipoint Door Lock (top hook to spindle = 610mm) - Image 3
Vitawin Latch 3 Hooks 2 Rollers Double Spindle Multipoint Door Lock (top hook to spindle = 610mm) - Image 4
Vitawin Latch 3 Hooks 2 Rollers Double Spindle Multipoint Door Lock (top hook to spindle = 610mm) - Image 5
Vitawin Latch 3 Hooks 2 Rollers Double Spindle Multipoint Door Lock (top hook to spindle = 610mm) - Image 6

Vitawin Latch 3 Hooks 2 Rollers Double Spindle Multipoint Door Lock (top hook to spindle = 610mm)

SKU: VIT3H2R35DSconfig

£56.22 Out of stock

SKU: VIT3H2R35DSconfig Categories: , Brand:

Description

This part is discontinued and is no longer available.

However, part: FUXLCOMP3H4R35 is a potential alternative. This is a similar size lock with the hooks in the same position but this lock will have 4 rollers. Use in conjunction with full length keep order codes FUXLK4RKEEPL or FUXLK4RKEEPR.

Part: VITACASE35OLD is a potential alternative.

Additional information

Manufacturer

Vitawin
Discontinued

Yes
Backset

35mm
Centres PZ

92mm/62mm
Faceplate

Flat 16mm – Square Ends
Spindle Size

8mm
Rollers

2
Hooks

3
Main Gearbox

Latch and hookbolt
Operation

Double Spindle
Spindle

Double 8mm
1, 2 or 3 Piece

1
Handing

Non Handed
Distance Between Inner Locking Points

1220mm
Distance Between Outer Locking Points

1392mm
Height

2200mm
Top Hook To Spindle

610mm
Bottom Hook To Spindle

610mm
Top Roller To Spindle

696mm
Bottom Roller To Spindle

696mm
